Vitrified bond diamond grinding wheel is a high-performance grinding tool made of ceramic as bonding material and diamond as abrasive. It has high hardness, heat resistance and precision machining capabilities, and is widely used in the processing of hard and brittle materials and superhard tools.
The hardness of ceramic binder far exceeds that of resin and metal binder, the service life of grinding wheel can reach more than 3 times that of resin grinding wheel, and the loss of abrasive grains is extremely low;
Sharp cutting, high grinding efficiency, not easy to heat up and clog during processing, low temperature rise, and can effectively control the surface damage of workpiece;
Small grinding force, good workpiece shape retention, surface roughness can reach Ra0.1μm or less;
Heat-resistant (resistant to high temperature of 1200℃), acid and alkali corrosion resistance, suitable for various grinding fluids, suitable for high-speed and high-precision scenes;
|
Diameter (D) |
Hole (H) |
Thickness (T) |
Abraive Width (W) |
Abraive Hight (X) |
Grit |
Concentration (C) |
|
50mm-800mm/Customized |
12.7mm-32mm/Customized |
1mm-40mm/Customized |
1mm-20mm/Customized |
1mm-20mm/Customized |
Customized |
Customized |
